Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Operating Input Voltage(Min) 2.5V
Maximum Supply Voltage 12V
Channel Output Current 500mA (Switch)
Frequency 1MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN (3x2)
Win Source Part Number 020413-LT3591EDDB#TRMPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT3591EDDB#TRMPBF CAD Model

Description

The LT3591EDDB#TRMPBF is a high-performance LED driver integrated circuit from Linear Technology designed to efficiently power and control LEDs in a compact package. This product is part of Linear Technology's extensive range of power management solutions and is ideal for portable and compact applications requiring high-efficiency LED driving capabilities.

Key Features

  • Adjustable Output Voltage: The device offers an adjustable output voltage that can be set with a single external resistor, providing flexibility for various LED configurations.
  • High Efficiency: With its internal 36V, 1MHz DC/DC boost converter, the LT3591EDDB#TRMPBF operates with high efficiency, which is crucial for battery-powered applications.
  • Integrated Schottky Diode: The inclusion of an integrated Schottky diode simplifies the design and reduces external component count, saving space and cost.
  • True Color PWM Dimming: The device supports True Color PWM dimming, which delivers constant LED color with deep dimming capability, essential for high-quality lighting applications.
  • Wide Input Voltage Range: It operates across a wide input voltage range of 3V to 30V, accommodating a variety of power sources.
  • Compact Package: The LT3591EDDB#TRMPBF is available in a small 8-lead (3mm × 3mm) DFN package, making it suitable for space-constrained applications.

Applications

The versatility of the LT3591EDDB#TRMPBF makes it an excellent choice for a broad array of applications, including:

  • Portable lighting
  • Automotive and avionics lighting
  • Backlighting for LCD displays
  • General-purpose LED illumination

Quality and Reliability

Linear Technology is known for its commitment to quality, and the LT3591EDDB#TRMPBF is no exception. It is designed to meet stringent requirements, ensuring reliable performance in a range of environmental conditions. The product is available in tape and reel packaging, designated by the TRMPBF suffix, which facilitates efficient assembly processes for high-volume production.

With its robust feature set and Linear Technology's reputation for high-quality, reliable components, the LT3591EDDB#TRMPBF LED driver is an excellent choice for designers looking to enhance the performance and efficiency of their LED lighting solutions.
