Products specifications

Manufacturer Linear Technology
Win Source Part Number 1206824-LT4256-2CS8
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT4256-2CS8 CAD Model

Description

Linear Technology LT4256-2CS8 Hot Swap Controller

The LT4256-2CS8 by Linear Technology is a sophisticated hot swap controller designed to allow safe board insertion and removal from a live backplane. This device comes in a compact 8-lead SO package and is engineered to manage electronic circuit power supply connections by controlling the inrush current during system hot-swap events. It is an essential component for high-availability systems that require maintenance or upgrades without powering down the system.

The LT4256-2CS8 features a wide operating voltage range from 9V to 80V, making it versatile for various applications, including telecom, datacom, and industrial systems. It provides an adjustable current limit, which can be set via a single external resistor, offering designers flexibility to tailor the inrush current to specific system requirements.

One of the key attributes of the LT4256-2CS8 is its ability to protect against overcurrent conditions. The device's foldback current limiting helps reduce the power dissipation in the MOSFET during overcurrent conditions. Additionally, it offers an automatic retry feature, which allows the system to attempt to power back up after a fault condition without human intervention, improving system reliability.

The controller also includes a range of diagnostic features. It has a status flag that indicates when the output voltage is within a specified range, and a fault flag that signals overcurrent, overtemperature, or power bad conditions. These features enable easy monitoring and fault diagnosis, which is critical for maintaining system uptime.

For timing control, the LT4256-2CS8 provides an adjustable timer that sets the duration of the overcurrent fault condition before the controller shuts down the gate voltage. This timer can be set with an external capacitor, offering further customization to the system designer.

Overall, the LT4256-2CS8 is a robust solution for power management in systems that require hot-swapping capability. It ensures smooth and safe power delivery and protects both the electronic system and the user during insertion and removal of boards in live systems.
