Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, Cuk, SEPIC
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.55V
Maximum Input Voltage 40V
Nominal Output Voltage (Min/Fixed) 1.2V
Maximum Output Voltage 65V (Switch)
Output Current 1.2A (Switch)
Frequency - Switching 200kHz to 1.5MHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN (3x3)
Win Source Part Number 1060242-LT8580EDD#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LT8580
Introduction Date July 16, 2014
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT8580EDD#TRPBF CAD Model

Description

The LT8580EDD#TRPBF is a sophisticated boost converter integrated circuit (IC) from Linear Technology, designed to deliver high efficiency and performance for a wide range of power supply applications. This versatile component is capable of generating a boosted output voltage from a lower input voltage, making it ideal for applications requiring a step-up voltage conversion.

Key Features:

  • Wide Input Voltage Range: The device is capable of operating from an input voltage range of 2.55V to 40V, accommodating a broad spectrum of power sources.
  • Adjustable Output Voltage: The output voltage is adjustable up to 40V, providing flexibility for various design requirements.
  • High Efficiency: With its internal 1A, 42V switch, the LT8580EDD#TRPBF can achieve efficiency levels that minimize power loss and heat generation.
  • Small Footprint: Housed in a compact 10-lead DFN package, this IC saves valuable board space in dense designs.
  • Integrated Features: The device includes soft-start capability, frequency foldback, and thermal protection for reliable operation under a range of conditions.
  • Low Ripple: The LT8580EDD#TRPBF delivers low ripple output, which is critical for noise-sensitive applications.

Applications:

The LT8580EDD#TRPBF is well-suited for a variety of applications, including but not limited to:

  • Portable Electronics
  • Automotive and Industrial Power Systems
  • Battery-Powered Devices
  • LED Driver Circuits
  • Medical Equipment

Quality and Reliability:

Linear Technology is renowned for its commitment to quality, and the LT8580EDD#TRPBF is no exception. It is designed to meet high standards of performance and reliability, ensuring stable operation in a variety of environmental conditions.

Ordering Information:

The product is available in a RoHS-compliant package and is designated with the #TRPBF suffix, indicating tape and reel packaging for use in automated manufacturing environments. For detailed ordering and shipping information, please refer to the official Linear Technology datasheets and product guides.
