Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol Multiprotocol
Number of Drivers/Receivers 5/3
Duplex Full
Receiver Hysteresis 15mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 36-SSOP
Win Source Part Number 041251-LTC1545CG
Ultra Librarian 3D Model Ultra Librarian LTC1545CG CAD Model

Description

The LTC1545CG is a versatile interface transceiver from Linear Technology, designed to simplify the design of industrial control systems, networked devices, and data communication equipment. This integrated circuit is housed in a compact 28-lead SSOP package, making it suitable for space-constrained applications.

Key Features

  • Integrated Transceiver: The LTC1545CG combines a 5V RS232 dual driver/receiver, a 5V RS485 differential transceiver, and a 5V isolated 20Mbps cable transceiver in one chip, providing a comprehensive solution for various communication protocols.
  • Wide Operating Temperature Range: With an operational temperature range from 0°C to 70°C, the LTC1545CG is reliable for use in diverse environments.
  • Low Power Consumption: The device is designed to operate with low power consumption, which is critical for battery-powered and energy-efficient applications.
  • Flexible Power Supply: The LTC1545CG operates from a single 5V supply, simplifying power management within the system.
  • High-Speed Operation: The integrated cable transceiver can operate at speeds up to 20Mbps, making it suitable for high-speed data communication tasks.

Applications

The LTC1545CG is ideal for a range of applications including:

  • Industrial control systems
  • Data communication equipment
  • Networked devices
  • Point of sale systems
  • Factory automation

Conclusion

The LTC1545CG from Linear Technology is a multifunctional interface transceiver that offers a blend of versatility, reliability, and performance for communication interfaces. Its ability to support multiple protocols and its high-speed operation make it an excellent choice for designers looking to streamline their systems with a single, efficient solution. Whether for industrial environments, commercial applications, or communication infrastructures, the LTC1545CG stands out as a robust component in any electronic system.
