Manufacturer Linear Technology
Win Source Part Number 1208058-LTC1772CS6
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC1772CS6 CAD Model

Description

The LTC1772CS6 from Linear Technology is a highly efficient, constant frequency, current mode pulse width modulation (PWM) step-down DC/DC converter. Packaged in a compact SOT-23 package, this device is designed to minimize external component count while providing a versatile solution for power management requirements.

Key Features:

  • High Efficiency: The LTC1772CS6 offers up to 96% efficiency, which is ideal for battery-powered applications where maximizing battery life is critical.
  • Wide Input Voltage Range: This converter operates over a wide input voltage range from 2.65V to 8.4V, making it suitable for a variety of single-cell Li-Ion or multi-cell alkaline/NiCd/NiMH applications.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to VIN, providing flexibility for different voltage requirements.
  • Low Quiescent Current: Its low quiescent current of 25uA (typical) during operation and 10uA in shutdown mode ensures minimal power drain when idle.
  • High Switching Frequency: With a 550kHz fixed frequency operation, the LTC1772CS6 allows the use of small surface mount inductors and capacitors, saving space on the PCB.
  • Stable with Low ESR Ceramic Capacitors: The device is stable with ceramic output capacitors, which are smaller, more reliable, and have lower ESR compared to electrolytic capacitors.
  • Burst Mode® Operation: The LTC1772CS6 features Burst Mode operation, which reduces quiescent current to just 10uA during light load conditions, further improving battery life.
  • Short-Circuit Protection: The built-in short-circuit protection enhances the safety and reliability of the power supply design.

Applications:

  • Portable Instruments
  • Battery-Powered Equipment
  • Cellular Telephones
  • Wireless Modems
  • PDAs and Handheld Computers

The LTC1772CS6 is an excellent choice for designers who require a compact, efficient, and flexible power solution. Its ability to deliver high efficiency across a wide range of load conditions makes it particularly suitable for portable devices where extending battery life is paramount.
