Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Buffer, Accelerator
Applications I2C - Hotswap
Input 2-Wire Bus
Output 2-Wire Bus
Data Rate (Max) 400kHz
Number of Channels 2
Capacitance - Input 10pF
Supply Voltage - Operating 2.3 V to 5.5 V
Operating Supply Current 8mA
Temperature Range - Operating 0°C to 70°C
Case / Package 8-MSOP
Win Source Part Number 140613-LTC4307CMS8#TRPBF
Ultra Librarian 3D Model Ultra Librarian LTC4307CMS8#TRPBF CAD Model

Description

LTC4307CMS8#TRPBF - I2C Bus Buffer and Hot Swap Controller

The LTC4307CMS8#TRPBF is a high-performance I2C bus buffer and hot swap controller from Linear Technology, designed to facilitate the reliable operation of I2C systems. This innovative component ensures that I2C buses can be extended and multiple devices can be connected without the risk of data corruption or signal integrity issues. It is particularly ideal for complex systems where multiple I2C devices are required to communicate efficiently and reliably.

This device features robust hot swap capabilities, which allow users to connect and disconnect devices from the I2C bus without having to power down the system. This feature is essential for systems that require maintenance or upgrades without interrupting the operation of other devices on the bus. The LTC4307CMS8#TRPBF provides a seamless and safe way to manage the I2C bus connections, ensuring minimal downtime and enhanced system flexibility.

One of the key attributes of the LTC4307CMS8#TRPBF is its level shifting capability, which allows it to connect I2C buses with different voltage levels. This means that devices operating at various logic levels can communicate with each other without the need for additional level translators. The device supports a wide operating voltage range, making it suitable for a variety of applications.

The LTC4307CMS8#TRPBF also includes a strong slew-rate-limited rise time accelerator to enhance the signal integrity over long cables or high-capacitance bus lines. This feature is critical in maintaining the speed and reliability of the I2C communication, even in challenging electrical environments.

With built-in fault protection, the LTC4307CMS8#TRPBF actively protects the bus from stuck low conditions, which can occur due to hardware failures or software issues. This ensures that the I2C bus remains operational, and communication between devices is maintained without interruption.

Designed in a compact MSOP-8 package, the LTC4307CMS8#TRPBF is suitable for space-constrained applications, providing a powerful solution for I2C bus buffering and hot swap control without compromising on board real estate.

Overall, the LTC4307CMS8#TRPBF is an essential component for any application that relies on the I2C protocol for communication between multiple devices, offering enhanced reliability, flexibility, and protection for sophisticated electronic systems.
