Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Type Source Selector Switch
Polarity P-Channel
Internal Switch(s) Yes
Delay Time - ON 50μs
Delay Time - OFF 4μs
Current - Output (Max) 2.6A
Operating Supply Current 25μA
Supply Voltage - Operating 2.5 V to 5.5 V
Applications Handheld/Mobile Devices
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 142776-LTC4413EDD#PBF
Ultra Librarian 3D Model Ultra Librarian LTC4413EDD#PBF CAD Model

Description

Linear Technology LTC4413EDD#PBF Dual Diode ORing PowerPath Controller

The LTC4413EDD#PBF from Linear Technology is a sophisticated PowerPath controller designed to enhance system reliability by orchestrating dual power sources in a seamless and efficient manner. This component is particularly well-suited for applications that require a constant and uninterrupted power supply, such as servers, communication equipment, and industrial systems.

Encased in a compact DFN (10-lead plastic DFN) package, the LTC4413EDD#PBF boasts a low on-resistance of just 50mΩ, minimizing voltage drop and power loss, which is crucial for maintaining efficiency in power-sensitive designs. The device operates with a supply voltage range from 2.5V to 5.5V, making it versatile for various low-voltage applications.

One of the standout features of the LTC4413EDD#PBF is its ability to control two N-channel MOSFETs to create a near-ideal diode function for power switch-over and load sharing. This functionality ensures that if one power source fails or is disconnected, the other source can take over immediately without any interruption to the load. Additionally, the controller provides reverse blocking and thermal protection to safeguard against reverse currents and overheating, respectively.

The LTC4413EDD#PBF integrates seamlessly into systems requiring a prioritized power supply hierarchy. For example, a primary source can be used preferentially until it is no longer available, at which point the secondary source is automatically engaged. This prioritization is particularly useful in systems with battery backup or redundant power supplies.

Furthermore, the LTC4413EDD#PBF's low quiescent current of 11μA (typical) ensures minimal drain on the power sources when in standby mode. This feature is critical for battery-powered applications where conserving energy is paramount.

In summary, the Linear Technology LTC4413EDD#PBF is a highly reliable and efficient solution for managing dual power sources in critical systems. Its robust feature set, including fast switch-over, low on-resistance, and thermal protection, makes it an ideal choice for designers looking to enhance the resiliency and efficiency of their power management systems.
