The LTC491IS#PBF is a high-quality differential bus transceiver designed by Linear Technology, now part of Analog Devices, to provide robust data communication on balanced transmission lines. It is an integral component for applications requiring high-speed, low-power operation in challenging electrical environments. This product is specifically tailored for bidirectional data communication on multipoint bus transmission lines.

Key Features

• Interface Type: RS485/RS422
• Supply Voltage Range: 4.75V to 5.25V
• Operating Temperature Range: -40°C to +85°C
• Package: 14-Pin Narrow SOIC
• Mounting Type: Surface Mount
• ESD Protection: Enhanced electrostatic discharge protection
• Speed: Up to 2.5Mbps
• Low Power Shutdown Mode: Minimizes power consumption when not in active use
• Fail-Safe Receiver: Ensures a logic-high receiver output when the receiver inputs are open or shorted

Product Applications

The LTC491IS#PBF is ideally suited for a variety of industrial, telecommunications, and networking applications. Its differential signaling provides immunity to electrical noise, which is essential for reliable operation in industrial environments. Some of the common applications include:

• Networked control systems
• Industrial automation and process control
• Remote data acquisition
• Building automation
• Point-of-sale systems

Quality and Reliability

Linear Technology is known for its commitment to manufacturing high-reliability products. The LTC491IS#PBF is built to meet stringent quality standards, ensuring consistent performance and durability. Its extended temperature range and robust ESD protection make it suitable for demanding applications where uptime and reliability are critical.

Environmental Compliance

The LTC491IS#PBF complies with RoHS (Restriction of Hazardous Substances) standards, reflecting Linear Technology's dedication to environmental responsibility. This compliance ensures that the product is free from specific hazardous materials commonly used in electronics and electrical equipment.
