Win Source Part Number 1030601-LTC6803G4
Categories OEM Parts(J-L)
Manufacturer Linear Technology
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian LTC6803G4 CAD Model

Description

Introducing the LTC6803G4 from Linear Technology

The LTC6803G4 is a highly integrated, multicell battery stack monitor that represents a leap forward in battery monitoring technology. This sophisticated IC is designed to measure up to 12 series-connected battery cells with a total measurement error of less than 1.2mV. The device's robust architecture enables it to handle common-mode voltages up to 1000V, making it suitable for a wide range of battery configurations and chemistries.

One of the standout features of the LTC6803G4 is its ability to perform simultaneous cell voltage measurements, which greatly improves the speed and accuracy of the data acquisition process. This is particularly beneficial in systems where battery state-of-charge (SOC) and state-of-health (SOH) determinations are critical. The device uses a 4th-order Delta-Sigma analog-to-digital converter, ensuring high precision and noise rejection in the voltage measurement process.

The LTC6803G4 also includes a number of safety features that are crucial for battery management systems. It comes with an isoSPI interface, which allows for robust, high-speed communication with the host controller while providing galvanic isolation. This not only enhances safety but also improves noise immunity and allows for long-distance communications between the battery stack monitor and the controller.

For ease of integration into existing systems, the LTC6803G4 offers a straightforward SPI interface for configuration and readback. Additionally, it supports daisy-chaining of multiple devices, enabling the monitoring of an extended series of battery cells without the need for complex wiring or additional hardware.

Linear Technology's LTC6803G4 is an ideal solution for a variety of applications, including electric vehicles (EVs), hybrid electric vehicles (HEVs), and large-scale energy storage systems, where accurate and reliable battery monitoring is essential. With its advanced features and high level of integration, the LTC6803G4 simplifies the design of battery management systems and enhances their performance and safety.

Overall, the LTC6803G4 is a testament to Linear Technology's commitment to providing innovative solutions for the rapidly growing field of battery technology. It is designed to meet the stringent requirements of today's most advanced battery systems, ensuring that they operate safely, efficiently, and reliably over their entire lifespan.
