Same model may have multiple batches, images only for reference.

SMBJ33A

Name: SMBJ33A
Brand: Littelfuse Inc.
SKU: 328051
Availability: InStock
Rating: 4.85 (85 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMBJ33A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 33VWM 53.3VC SMB
Datasheet	SMBJ33A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection
Family	TVS - Diodes
Manufacturer	Littelfuse Inc.
Series	SMBJ
Packaging	Reel(TR)
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	33V
Voltage - Breakdown (Min)	36.7V
Voltage - Clamping (Max) @ Ipp	53.3V
Current - Peak Pulse (10/1000μs)	11.3A
Power - Peak Pulse	600W
Power Line Protection	No
Applications	General Purpose
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	DO-214AA, SMB
Manufacturer Device Package	DO-214AA (SMBJ)
Win Source Part Number	029208-SMBJ33A
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Communications & Networking, Computers & Computer Peripherals, Imaging, Video & Vision, Industrial
Package	Strip
Product Status	Active
Current - Peak Pulse (10/1000µs)	11.26A
Operating Temperature	-55°C ~ 150°C
Grade	-
Mounting Type	Surface Mount
Package / Case	DO-214AA (SMB)
Package	Tape & Reel (TR);Cut Tape (CT)
Current - Peak Pulse (10/1000µs)	11.3A
Power Line Protection	Yes
Package / Case	DO-214AA, SMB
Supplier Device Package	DO-214AA (SMBJ)
Ultra Librarian 3D Model	Ultra Librarian SMBJ33A CAD Model

Alternative Products

Description

The Littelfuse Inc. product with Win Source Part Number 029208-SMBJ33A is a high-quality TVS - Diodes electronic component that is widely used in various electronic devices.

Applications: communications and networking, computers and computer peripherals, imaging, video and vision, and industrial
Manufacturer: Littelfuse Inc.
Operating Temperature Range: -55°C to 150°C
