Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Obsolete(EOL)
Type Function Generator
PLL No
Input CMOS, TTL
Output CMOS, TTL
Number of Circuits 1
Maximum Input Frequency 40MHz
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 20-PDIP
Win Source Part Number 021077-MAX038CPP+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX038
Introduction Date February 01, 1995
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MAX038CPP+ CAD Model

Description

Introducing the MAX038CPP+ High-Frequency Waveform Generator

The MAX038CPP+ is a cutting-edge, high-frequency, precision waveform generator designed by Maxim Integrated to meet the needs of advanced communication systems, signal processing, and test equipment applications. This versatile integrated circuit (IC) is capable of producing accurate sine, square, and triangle waveforms with a frequency range up to 20MHz.

Key Features

  • Wide Frequency Range: The MAX038CPP+ offers a broad frequency range from 0.1Hz to 20MHz, enabling its use in a variety of applications that require high-speed signal generation.
  • Waveform Versatility: It generates high-quality sine, square, and triangle waveforms, making it a flexible choice for different types of electronic testing and signal processing tasks.
  • High Stability: The oscillator stability is excellent, ensuring that the output frequency remains consistent under varying conditions.
  • Adjustable Duty Cycle: For square wave generation, the duty cycle is adjustable from 0% to 100%, which is ideal for creating custom pulse-width modulated (PWM) signals.
  • Low Distortion: The sine wave output of the MAX038CPP+ has low distortion, which is crucial for applications that require a clean signal.

Applications

The MAX038CPP+ is suitable for a diverse range of applications, including:

  • Function generators
  • Frequency synthesizers
  • Phase-locked loops (PLLs)
  • Communication equipment
  • Benchtop test and measurement equipment
  • Arbitrary waveform generation

Easy Integration

Designed in a compact, 20-pin DIP package, the MAX038CPP+ can be easily integrated into existing designs, saving space on the PCB while providing high functionality. It requires minimal external components, which simplifies the design process and reduces the overall system cost.

Conclusion

The MAX038CPP+ from Maxim Integrated stands out as an exemplary waveform generator IC, offering high-frequency capabilities, waveform versatility, and stability. Its wide range of applications and ease of integration make it a top choice for engineers and designers looking to create sophisticated electronic systems and perform precise testing and measurement tasks.
