Products specifications

Category Development Boards, Kits, Programmers - Evaluation and Demonstration Boards and Kits
Mfr Analog Devices Inc./Maxim Integrated
Package Box
Type Power Management
Function Gate Driver
Utilized IC / Part MAX22701
Primary Attributes Isolated
Supplied Contents Board(s)
Secondary Attributes Single-Ended
Base Product Number MAX22701
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1348470-MAX22701EVKIT#
Ultra Librarian 3D Model Ultra Librarian MAX22701EVKIT# CAD Model

Description

MAX22701EVKIT# Evaluation Kit by Maxim Integrated

Maxim Integrated's MAX22701EVKIT# is a comprehensive evaluation kit designed for assessing the performance and capabilities of the MAX22701 high-speed, single-channel gate driver. This evaluation kit is an essential tool for engineers and designers who are looking to explore the features of the MAX22701 gate driver in various applications, including motor control, power inverters, and switching power supplies.

Key Features

  • High-Performance Gate Driving: The MAX22701 gate driver is capable of delivering peak currents up to 2.5A, making it suitable for driving a wide range of MOSFETs and IGBTs.
  • Advanced Protection: Integrated features such as UVLO (Under Voltage Lock Out), Miller clamp, and desaturation detection ensure reliable operation and protection for the power devices.
  • High CMTI: With a Common-Mode Transient Immunity (CMTI) of 300kV/µs, the MAX22701 provides stable performance in noisy environments, reducing the risk of erroneous gate driving.

Flexible Configuration

The MAX22701EVKIT# offers a flexible platform that allows users to configure the gate driver for different operating conditions. The evaluation kit includes configurable options for dead-time insertion, UVLO settings, and drive strength, enabling users to tailor the driver to their specific needs.

User-Friendly Interface

Designed with ease of use in mind, the MAX22701EVKIT# includes an intuitive user interface with test points and jumper options. This allows for quick measurements and adjustments without the need for complex setup procedures.

Comprehensive Documentation

Maxim Integrated provides detailed documentation for the MAX22701EVKIT#, including a user manual, application notes, and schematic diagrams. This documentation ensures that users can get up and running quickly while also providing in-depth information for advanced experimentation and design integration.

Robust Design

The evaluation kit is built with robust components and adheres to Maxim's high-quality standards. It is designed to withstand the rigors of extensive testing, providing a reliable platform for evaluating the MAX22701 gate driver's performance in various conditions.

In summary, the MAX22701EVKIT# from Maxim Integrated is an indispensable tool for engineers looking to fully explore the capabilities of the MAX22701 gate driver. With its high-performance features, flexible configuration options, and comprehensive support materials, this evaluation kit is poised to accelerate the development of sophisticated power management solutions.
