Products specifications

Estimated EOL Date Obsolete / End of life
Halogen Free Compliant
ECCN EAR99
Introduction Date February 17, 2014
Family Name MAXREFDES23
Supply and Demand Status Limited
Popularity Medium
Win Source Part Number 787080-MAXREFDES27#
Utilized IC / Part MAX8532, MAX14821, MAX17552, MAX44000
Supplied Contents Board(s)
Interface Serial
Sensor Type Proximity
Series Himalaya
Manufacturer Maxim Integrated
Categories Development Boards, Kits, Programmers
Ultra Librarian 3D Model Ultra Librarian MAXREFDES27# CAD Model

Description

Introducing the MAXREFDES27# - Your Robust Industrial IO Solution

The MAXREFDES27# from Maxim Integrated is a cutting-edge reference design that addresses the need for resilient and high-performing industrial input/output solutions. This remarkable product is designed to serve as an ideal platform for developers looking to implement industrial control systems with a focus on reliability and precision.

Key Features

  • High Integration: The MAXREFDES27# integrates a 16-bit, high-accuracy, ADC and a 16-bit, high-accuracy, DAC, providing a complete analog front-end solution for control and automation applications.
  • Robust Design: With its emphasis on durability, it is built to withstand the harsh conditions commonly found in industrial environments, including exposure to high temperatures, electrical noise, and mechanical stress.
  • Flexible Communication: It supports industrial communication protocols such as I2C, SPI, and UART, allowing for easy integration into existing systems.
  • Isolated IO: The reference design features galvanic isolation, ensuring that the data and power domains are separated, thus providing protection against high voltage spikes and ground loops.

Applications

The MAXREFDES27# is well-suited for a variety of applications, including:

  • Process control systems
  • Data acquisition systems
  • Industrial automation
  • PLC (Programmable Logic Controllers)

Technical Specifications

At its core, the MAXREFDES27# boasts a robust set of technical specifications that make it a powerhouse for industrial applications:

  • 16-bit ADC with a sampling rate of up to 500ksps
  • 16-bit DAC with precision voltage output
  • Wide operating temperature range, ensuring reliable performance under extreme conditions
  • Compact form factor for easy integration into a variety of systems

Developers and engineers will find the MAXREFDES27# to be an invaluable tool in their arsenal, providing a reliable foundation for building sophisticated control systems. With its robust design and versatile features, it stands out as a premier choice for those seeking to enhance the capabilities of their industrial applications.
