Products specifications

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr MDD
Series DFN1006
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 3.3V (Max)
Voltage - Breakdown (Min) 5V
Current - Peak Pulse (10/1000µs) 5A (8/20µs)
Power - Peak Pulse 105W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 105pF @ 1MHz
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case DFN1006
Supplier Device Package DFN1006
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1362268-ESD8D3V3
Ultra Librarian 3D Model Ultra Librarian ESD8D3V3 CAD Model

Description

The 1362268-ESD8D3V3 is a Zener type TVS diode designed for circuit protection against transient voltage events.

  • Diode Type: Zener
  • Voltage Reverse Standoff: 3.3V
  • Breakdown Voltage Minimum: 5V
  • Peak Pulse Current: 5A (10/1000µs)
  • Peak Power Rating: 105W
  • Application: General Purpose
  • Mounting Type: Surface Mount
  • Package: DFN1006
  • Protection Feature: Power Line
  • Capacitance: 105pF @ 1MHz
  • Series: DFN1006
  • Packaging: Tape and Reel
  • Operating Temperature: -55°C to 125°C (TJ)
  • REACH: Unaffected
  • ECCN: EAR99
