SS310C Rugao Dachang Electronics Co., Ltd
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMC
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 850 mV @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 300 µA @ 100 V
Capacitance @ Vr, F 350pF @ 4V, 1MHz
Mounting Type Surface Mount
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 676335-SS310C
Ultra Librarian 3D Model Ultra Librarian SS310C CAD Model

Description

The SMC is a fast recovery Schottky diode from MDD.

  • Voltage: 100V
  • Current: 3A
  • Forward Voltage Drop: 850mV @ 3A
  • Mounting: Surface mount applications
  • Package: Tape & reel
  • Application: Suitable for rectification purposes in various electronic circuits.
  • Reverse Leakage Current: 300 µA @ 100V
  • Capacitance: 350pF @ 4V, 1MHz
  • Speed: Fast recovery speed
  • Suitable for: High-frequency applications
  • Status: An active product
  • Standard Package: 3,000 pcs.
