The SR2080C is a Schottky Barrier Rectifier manufactured by MIC GROUP RECTIFIERS. This rectifier is designed for high-efficiency rectification in various power supply and switching applications. It features a low forward voltage drop and fast switching speed, making it suitable for high-frequency applications.

Applications:

• Switching Power Supplies: Used in SMPS (Switched-Mode Power Supplies) to improve efficiency.
• DC-DC Converters: Employed in DC-DC converters for voltage regulation and conversion.
• Freewheeling Diodes: Utilized as freewheeling diodes in inductive circuits.
• Polarity Protection: Integrated into circuits for reverse polarity protection.
• LED Lighting: Found in LED lighting systems for efficient power conversion.

Features:

• Low Forward Voltage Drop: Minimizes power loss and improves efficiency.
• Fast Switching Speed: Enables high-frequency operation with minimal switching losses.
• High Surge Current Capability: Designed to withstand high surge currents.
• High Reliability: Ensures long-term dependable performance.
• RoHS Compliant: Meets environmental standards for hazardous substances.

Benefits:

• Improved Efficiency: Reduces energy consumption and lowers operating costs.
• Reduced Heat Dissipation: Low forward voltage drop minimizes heat generation.
• Faster Switching: Enables higher operating frequencies in switching applications.
• Reliable Performance: Ensures stable and consistent operation.
• Environmentally Friendly: RoHS compliance ensures adherence to environmental regulations.

Additional Details:

The SR2080C Schottky rectifier features a maximum repetitive peak reverse voltage of 80V and a forward current of 20A. Its low forward voltage drop of typically 0.7V reduces power dissipation and improves overall efficiency. The fast switching speed of the rectifier allows for efficient operation at high frequencies. It is commonly used in switching power supplies, DC-DC converters, and LED lighting applications. The SR2080C is designed to withstand high surge currents, ensuring reliable operation under transient conditions. The compact package size facilitates its integration into various applications where space is limited. The rectifier is also designed to operate over a wide temperature range, ensuring reliable performance in diverse environmental conditions. The low reverse leakage current minimizes power losses and improves overall efficiency. The SR2080C is a reliable and efficient choice for applications requiring fast switching and low forward voltage drop. The robust construction and high surge current capability contribute to its long-term reliability in demanding applications.
