The 1N822 from Microchip Technology is a precision, low-power voltage reference device that offers a stable zener diode voltage reference in a three-terminal, DO-35 package. This product is designed to maintain high stability and reliability over a wide range of environmental conditions, making it an ideal choice for precision voltage calibration, voltage monitoring in power supplies, and as a reference source in analog circuits.
Key Features
- Stable Voltage Reference: The 1N822 provides a precise 6.2V output, which is maintained over temperature variations and time, ensuring consistent performance for critical applications.
- Low Dynamic Impedance: The dynamic impedance of the device is low, which enhances its performance in circuits where load conditions may change.
- Wide Operating Conditions: This product can operate over a broad range of ambient temperatures, typically from -55°C to +125°C, suitable for various industrial and military applications.
- Robust Package: Encased in a durable DO-35 glass package, the 1N822 is designed for through-hole mounting, providing a sturdy and reliable solution for printed circuit boards.
- Long-Term Stability: The voltage reference exhibits excellent long-term stability, which minimizes the need for recalibration and maintenance over the product's lifespan.
Applications
The versatility of the 1N822 allows it to be used in various applications, including but not limited to:
- Digital voltmeters
- Power supply monitors
- Precision regulators
- Analog-to-digital and digital-to-analog converters
- Electronic instrumentation
Quality and Reliability
Microchip Technology is committed to delivering high-quality products. The 1N822 voltage reference is subjected to rigorous testing and quality control measures to ensure it meets the industry standards for reliability and performance. Customers can trust this device to provide a stable reference in their electronic systems.
