Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 46 Weeks
Features ARM® Cortex®-M4 series Microcontroller IC 32-Bit 120MHz 1MB (1M x 8) FLASH 144-LQFP (20x20)
Manufacturer Microchip Technology
Series SAM4E
Package Tray
Core Processor ARM® Cortex®-M4
Core Size 32-Bit
Speed 120MHz
Connectivity CANbus, EBI/EMI, Ethernet, IrDA, SD, SPI, UART/USART, USB
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Number of I/O 117
Program Memory Size 1MB (1M x 8)
Program Memory Type FLASH
Supply Voltage 1.62V ~ 3.6V
Data Converters A/D 16x12b; D/A 2x12b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting Surface Mount
Package 144-LQFP
Case / Package 144-LQFP (20x20)
Family Name ATSAM4
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8542.31.0001
Quantity per package 60
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 862422-ATSAM4E16EA-AU
Ultra Librarian 3D Model Ultra Librarian ATSAM4E16EA-AU CAD Model

Description

Microchip Technology ATSAM4E16EA-AU Microcontroller

The ATSAM4E16EA-AU is a high-performance microcontroller from Microchip Technology, designed to cater to the demanding needs of modern embedded systems. This ARM Cortex-M4 based microcontroller is ideal for industrial control systems, automotive applications, and IoT devices, where efficiency, reliability, and processing power are of paramount importance.

At the heart of the ATSAM4E16EA-AU is a 32-bit ARM Cortex-M4 core, which operates at a maximum frequency of 120 MHz. This core is enhanced with a Floating Point Unit (FPU), single-cycle digital signal processing (DSP) instructions, and a memory protection unit (MPU), providing the computational power needed to handle complex algorithms and control tasks with ease.

The device comes with a substantial 1MB of embedded Flash memory and 128KB of SRAM, ensuring ample space for application code and data storage. Additionally, it features dual-bank Flash, allowing for safe and reliable firmware updates, a critical feature for systems requiring uninterrupted operation.

Connectivity options on the ATSAM4E16EA-AU are robust, with a range of interfaces including Ethernet MAC, Full-speed USB Device and embedded Host, two CAN controllers, and multiple serial communication modules (USART, UART, SPI, I2C). These interfaces enable the microcontroller to communicate with a variety of peripherals and networks, making it a versatile choice for connected applications.

The microcontroller also includes an array of analog features, such as a 16-channel 12-bit ADC, dual 2-channel 12-bit DACs, and analog comparators, making it suitable for interfacing with sensors and performing real-time data acquisition.

Safety and reliability are addressed with integrated hardware features like a brown-out detector, a watchdog timer, and a real-time clock. For secure applications, the ATSAM4E16EA-AU offers a hardware encryption module supporting AES and DES, ensuring data protection and secure communication.

The ATSAM4E16EA-AU is available in a 144-pin LQFP package, making it compatible with a range of PCB designs. Its extensive feature set and robust design make it an excellent choice for engineers looking to develop high-performance, secure, and reliable embedded systems.
