Products specifications

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr Microchip Technology
Series SAM D20E
Package Tape & Reel
Core Processor ARM® Cortex®-M0+
Core Size 32-Bit Single-Core
Speed 48MHz
Connectivity I2C, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, WDT
Number of I/O 26
Program Memory Size 64KB (64K x 8)
Program Memory Type FLASH
RAM Size 8K x 8
Supply Voltage - Operating 1.62V ~ 3.6V
Data Converters A/D 10x12b; D/A 1x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 32-VFQFN Exposed Pad
Supplier Device Package 32-VQFN (5x5)
Base Product Number ATSAMD20
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Other Names ATSAMD20E16A-MUTDKR,ATSAMD20E16A-MUTCT,ATSAMD20E16A-MUTTR
Standard Package 5,000
Win Source Part Number 961191-ATSAMD20E16A-MUT
Ultra Librarian 3D Model Ultra Librarian ATSAMD20E16A-MUT CAD Model

Description

The ATSAMD20E16A-MUT is a high-performance, low-power microcontroller from Microchip Technology, designed to offer an optimal balance between power efficiency and processing capability. This microcontroller is part of the SAM D20 family, which is based on the powerful 32-bit ARM Cortex-M0+ processor. With its robust architecture, the ATSAMD20E16A-MUT is suitable for a wide range of applications, particularly those requiring significant computational power and minimal energy consumption, such as portable devices, sensor systems, and Internet of Things (IoT) endpoints.

Key Features

  • Core: ARM Cortex-M0+ CPU running at up to 48 MHz, offering an excellent balance of efficiency and performance.
  • Memory: 16KB of in-system self-programmable flash, 4KB of SRAM, and 2KB of EEPROM, providing ample storage for firmware and data.
  • I/O Options: A rich set of input/output options including multiple serial communication modules (SERCOM), which are fully configurable as UART/USART, I2C, or SPI interfaces.
  • Power Management: Features multiple power-saving modes to reduce power consumption during idle or low activity periods, making it ideal for battery-powered applications.
  • Analog Features: Equipped with 10-bit ADCs, analog comparators, and a DAC for versatile analog functionality.
  • Package: Available in a 32-pin QFN package, providing a compact footprint for space-constrained applications.
  • Operating Voltage: Supports a wide operating voltage range from 1.62V to 3.63V, allowing for flexibility in various power supply designs.
  • Temperature Range: Operates within an industrial temperature range of -40°C to +85°C, ensuring reliability in harsh environments.
  • Development Support: Compatible with Microchip's extensive range of development tools and software libraries, which simplify the design process and reduce time to market.

Applications

The ATSAMD20E16A-MUT is a versatile microcontroller that can be used in a variety of applications. Its power efficiency and processing capabilities make it an excellent choice for portable medical devices, smart metering, industrial control systems, and any application where efficient power management is a critical requirement.

With its advanced features and support for multiple communication protocols, this microcontroller is also well-suited for IoT devices, enabling smart, connected solutions that can communicate with other devices and cloud services seamlessly.
