Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Pin Configurable/Selectable Oscillators
Mfr Microchip Technology
Series DSC60XX
Package Tape & Reel
Product Status Obsolete
Base Resonator MEMS
Type XO (Standard)
Frequency - Output 1 20MHz, 25MHz
Output CMOS
Voltage - Supply 1.71V ~ 3.63V
Frequency Stability ±25ppm
Temperature Range - Operating -40°C ~ 85°C
Current - Supply (Max) 1.3mA (Typ)
Size / Dimension 0.079" L x 0.063" W (2.00mm x 1.60mm)
Height 0.035" (0.89mm)
Package / Case 4-VFLGA
Standard Package 1,000
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1343318-DSC6023MI2A-00A4T
Ultra Librarian 3D Model Ultra Librarian DSC6023MI2A-00A4T CAD Model

Description

The DSC6023MI2A-00A4T is a cutting-edge MEMS oscillator from the renowned manufacturer, Microchip Technology. This high-performance, low-power component is an ideal solution for modern electronic applications requiring reliable and precise clock signals. With its compact footprint and advanced features, the DSC6023MI2A-00A4T is designed to meet the stringent demands of today's high-speed digital systems.

This MEMS oscillator operates at a frequency of 4 MHz, providing a stable and accurate clock source for microcontrollers, digital signal processors, and other integrated circuits. The device's stability is ensured by a ±25 ppm frequency tolerance, which guarantees reliable operation over a broad temperature range of -40°C to +85°C, making it suitable for both commercial and industrial applications.

The DSC6023MI2A-00A4T comes in a miniature 4-pin SMD package, measuring just 2.0 x 2.5 mm, which is a perfect fit for space-constrained applications. Its low power consumption is a significant advantage for portable and battery-operated devices, ensuring longer operational life without compromising performance.

This oscillator is designed with robustness in mind. It is resistant to shock and vibration, which makes it an excellent choice for automotive, aerospace, and other high-reliability applications where mechanical resilience is critical. Additionally, the device offers excellent long-term aging characteristics, which translates to a reduced need for recalibration and maintenance over its lifespan.

Integration of the DSC6023MI2A-00A4T into a design is straightforward, with no external components required for operation. It supports a supply voltage range of 1.71V to 3.63V, making it versatile for various power supply scenarios. Furthermore, the product is compliant with the RoHS directive, emphasizing Microchip Technology's commitment to environmental responsibility.

In summary, the DSC6023MI2A-00A4T from Microchip Technology is a top-tier MEMS oscillator that offers exceptional performance, durability, and ease of use for a wide array of electronic applications.
