Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Protocol Ethernet
Function Controller
Interface PCI
Standards 10/100 Base-T/TX PHY
Supply Voltage (V) 3.3V
Supply Current 125mA
Temperature Range - Operating 0°C ~ 70°C
Manufacturer Package 128-TQFP
Supplier Device Package 128-VTQFP (14x14)
Family Part Number LAN9420
Manufacturer Pack Quantity 90
MSL Level 3 (168 Hours)
Win Source Part Number 1195041-LAN9420-NU
Manufacturer Homepage www.smsc.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LAN9420-NU CAD Model

Description

The LAN9420-NU from Microchip Technology is a high-performance, small-footprint, full-featured 10/100 Mbps Ethernet controller designed for embedded applications where performance, flexibility, and ease of integration are crucial. Its feature set makes it an ideal choice for a wide range of applications in the industrial, automotive, and consumer electronics markets.

Key Features

  • High-Speed Ethernet: The LAN9420-NU supports both 10BASE-T and 100BASE-TX networks, allowing for versatile connectivity options and fast data transfer rates.
  • Flexible Bus Interface: It features a 32-bit PCI 2.3 compliant interface, ensuring compatibility with a broad range of host processors.
  • Integrated PHY: The device comes with a built-in Ethernet PHY, which simplifies the design and reduces the bill of materials.
  • Low Power Consumption: Designed for energy efficiency, the LAN9420-NU is suitable for power-sensitive applications.
  • Support for Multiple Protocols: The controller supports a wide array of protocols including IPv4, TCP, UDP, and more, facilitating the development of complex network applications.
  • Auto-MDIX: The LAN9420-NU supports automatic MDI/MDIX crossover, eliminating the need for crossover cables and simplifying network installation and maintenance.

Applications

The versatility of the LAN9420-NU allows it to be used in a variety of applications, such as:

  • Industrial automation and control systems
  • Automotive infotainment and diagnostics
  • Consumer electronics like smart TVs and gaming consoles
  • Networking equipment including routers, switches, and networked printers
  • Medical devices requiring network connectivity

Support and Availability

Microchip Technology provides comprehensive support for the LAN9420-NU, including detailed datasheets, application notes, and design guides. Customers can also benefit from Microchip's global customer support network. The LAN9420-NU is available for order, ensuring that designers can incorporate this Ethernet controller into their designs with confidence in its long-term availability.
