Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT, N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 6A, 6A
Input Type Non-Inverting
Rise and Fall Time 20ns, 20ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 083861-MCP1407-E/SN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MCP1407-E/SN CAD Model

Description

Microchip Technology's MCP1407-E/SN MOSFET Driver

The MCP1407-E/SN is a high-speed MOSFET driver designed by Microchip Technology to provide high peak current output in a small package. This robust driver is capable of efficiently switching an N-Channel power MOSFET or an IGBT in a synchronous buck, boost, or full-bridge configuration. It's an ideal component for power management solutions in a variety of applications, including automotive, industrial, and consumer electronics.

Key Features:

  • High Peak Output Current: The MCP1407-E/SN can deliver up to 6A of peak output current, making it suitable for driving large capacitive loads with excellent transient response.
  • Wide Input Supply Voltage Range: It operates over a broad supply voltage range from 4.5V to 18V, which provides flexibility in various system designs.
  • Fast Rise and Fall Times: With rise and fall times typically less than 25ns, this driver ensures swift and efficient switching, thereby reducing switching losses and improving overall system efficiency.
  • Inverting Configuration: The MCP1407-E/SN is an inverting driver, which means it inverts the input signal at the output, providing design versatility.
  • Low Shoot-Through/Cross-Conduction Prevention: It features matched rise and fall times to help prevent shoot-through current in H-bridge and other configurations where cross-conduction can be an issue.
  • Thermal Protection: The device includes over-temperature protection to ensure reliable operation under a wide range of temperature conditions.
  • Latch-Up Protected: With latch-up protection up to 1.5A, the MCP1407-E/SN is robust against over-current conditions.
  • SOIC-8 Package: Housed in a small-outline integrated circuit (SOIC) package with 8 leads, the MCP1407-E/SN saves valuable board space without compromising performance.

Applications:

The MCP1407-E/SN is versatile and can be used in a wide array of applications, including:

  • DC/DC Converters
  • Motor Control Circuits
  • Power Supply Modules
  • LED Lighting Systems
  • Automotive Power Systems

With its high current capability, fast switching performance, and protective features, the MCP1407-E/SN from Microchip Technology is an excellent choice for designers looking to improve the reliability and efficiency of their power management systems.
