Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Packaging Reel - TR
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Input Voltage MIN 4.7V
Voltage Input MAX 36V
Output Voltage 2V
Output Voltage MAX 15V
Output Current 600mA
Frequency - Switching 500kHz
Synchronous Rectifier No
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting SMD
Package SOT-23-6
Manufacturer Package SOT-23-6
Win Source Part Number 1220922-MCP16301HT-E/CH
Manufacturer Homepage www.microchip.com
Popularity Medium
Supply and Demand Status Limited
Family Name MCP16301
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MCP16301HT-E/CH CAD Model

Description

Microchip Technology's MCP16301HT-E/CH High-Voltage Buck Converter

Microchip Technology's MCP16301HT-E/CH is a compact, high-efficiency, fixed-frequency, step-down DC-DC converter in a 6-lead SOT-23 package that provides a space-saving solution for a wide range of applications. This high-performance device is capable of handling an input voltage range from 4V to 30V and supports a maximum continuous output current of up to 600mA, making it an ideal choice for applications operating from a standard 5V, 12V, or 24V supply rails, or battery-powered applications.

The MCP16301HT-E/CH operates at a fixed frequency of 500 kHz, allowing for a good balance between efficiency and external component size. It features an integrated N-channel buck switch and is designed to deliver a regulated output voltage adjustable from 2V to 15V, which can be set using a pair of external resistors. This flexibility ensures that the MCP16301HT-E/CH can be tailored to power a variety of microcontrollers, sensors, and other electronic devices.

One of the key advantages of the MCP16301HT-E/CH is its high-temperature performance, with an extended operating junction temperature range of -40°C to +150°C, making it suitable for industrial and automotive applications that require reliable operation under harsh conditions. Additionally, its high efficiency helps to minimize power loss and heat generation, thereby reducing the need for heat sinks and simplifying thermal management.

The device includes a range of protective features to ensure stability and longevity, such as undervoltage lockout (UVLO), overtemperature protection, and overcurrent limit. These features help to safeguard the converter and the downstream components from various fault conditions. Moreover, the MCP16301HT-E/CH has a low shutdown current of 1 µA (typical), which is beneficial for battery-powered applications where power conservation is crucial.

In summary, the MCP16301HT-E/CH from Microchip Technology is an efficient, versatile, and reliable solution for generating lower supply voltages from higher voltage sources in a variety of electronic systems. Its small footprint, adjustable output, and robust protection features make it a popular choice for designers looking to optimize power management in their compact designs.
