Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Packaging Tube
Number of I/O 16
Interface SPI
Interrupt Output Yes
Output Type Open Drain
Current - Output Source/Sink 25mA
Clock Frequency 10MHz
Operating Supply Voltage 1.8 V ~ 5.5 V
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 28-SOIC (0.295", 7.50mm Width)
Manufacturer Package 28-SOIC
Win Source Part Number 1221023-MCP23S18-E/SO
Manufacturer Homepage www.microchip.com
Popularity Medium
Supply and Demand Status Balance
Family Name MCP23S18
Introduction Date September 29, 2008
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MCP23S18-E/SO CAD Model

Description

Microchip Technology MCP23S18-E/SO

The MCP23S18-E/SO from Microchip Technology is a versatile 16-bit I/O expander with serial interface for applications that require additional I/Os. This robust component is ideal for expanding the number of I/O points on microcontrollers, allowing for a more complex and feature-rich system design without the need for a larger microcontroller.

Key Features

  • Interface Type: The device uses an SPI interface, which provides a simple communication method with the host controller.
  • Number of I/Os: It features 16 I/O ports which can be individually configured as input or output, providing flexibility for a wide range of applications.
  • Operating Voltage: This expander operates at a voltage range of 1.8V to 5.5V, making it suitable for low-voltage and battery-powered systems.
  • High-Speed SPI Interface: It supports up to 10 MHz clock speeds, allowing for high-speed data transfer between the device and the microcontroller.
  • Enhanced Features: The MCP23S18-E/SO includes features such as internal pull-up resistors, interrupt output pins, and hardware address pins for easy expansion of up to eight devices on the same bus.

Applications

The MCP23S18-E/SO is suitable for a wide variety of applications, including:

  • Industrial control systems
  • Home automation
  • Automotive applications
  • Robotics
  • Consumer electronics

Package and Quality

The device is available in a 20-lead SOIC package, ensuring a compact footprint for space-constrained applications. It is also characterized for operation from -40°C to +125°C, providing reliable performance in extreme conditions.

With its robust feature set and Microchip's commitment to quality, the MCP23S18-E/SO is the perfect solution for designers looking to expand the capabilities of their microcontroller-based systems without a significant increase in size or complexity.
