Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Packaging Reel package
Number of Elements 2
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Dual Supply Voltage (±) 1.8 V ~ 5.5 V
Voltage - Input Offset (Maximum) 10mV @ 5.5V
Current - Input Bias (Maximum) 1pA @ 5.5V
Current - Output (Typ) 50mA
Maximum Quiescent Current 130μA
CMRR, PSRR (Typ) 66dB CMRR, 70dB PSRR
Propagation Delay (Maximum) 80ns
Hysteresis 5mV
Operating Temperature Range -40°C ~ 125°C
Package 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Mounting SMD
Manufacturer Package 8-MSOP
Win Source Part Number 788332-MCP6562T-E/MS
Popularity Medium
Supply and Demand Status Limited
Family Name MCP6562
Introduction Date March 30, 2009
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MCP6562T-E/MS CAD Model

Description

Microchip Technology MCP6562T-E/MS Operational Amplifier

The MCP6562T-E/MS from Microchip Technology is a high-performance, dual operational amplifier (op-amp) that offers a perfect blend of speed, precision, and low power consumption. Designed for advanced analog applications, this op-amp is ideal for battery-powered devices and other systems where power efficiency is paramount.

This operational amplifier features a quiescent current of just 1 mA (typical) per amplifier, which significantly extends the battery life in portable applications. With a gain bandwidth product of 1 MHz, the MCP6562T-E/MS is capable of handling a wide range of frequencies, making it suitable for audio processing, filter circuits, and many other signal conditioning tasks.

The MCP6562T-E/MS operates at a supply voltage range of 1.8V to 6.0V, allowing it to be used in low-voltage systems as well as more traditional 5V designs. This flexibility makes it an excellent choice for a broad array of applications, from automotive to industrial control systems.

One of the key advantages of this op-amp is its rail-to-rail input and output swing, which enables the amplifier to approach the power supply rails, thus maximizing the dynamic range in applications. Additionally, the MCP6562T-E/MS boasts a low input bias current and a low input offset voltage, ensuring high accuracy and a stable performance over time and temperature.

The device comes in an MSOP-8 (Micro Small Outline Package) form factor, which is ideal for space-constrained applications. The small size does not compromise its robustness, as it is specified for the extended temperature range of -40°C to +125°C, ensuring reliable operation in harsh environments.

In summary, the Microchip Technology MCP6562T-E/MS operational amplifier is a versatile and efficient solution for a multitude of electronic circuits requiring high performance and low power consumption. Its advanced features and compact footprint make it an excellent choice for designers looking to optimize their applications without sacrificing quality or functionality.
