Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 1
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Supply Voltage - Operating 1.8 V to 5.5 V
Voltage - Input Offset (Max) 10mV @ 5.5V
Current - Input Bias (Max) 1pA @ 5.5V
Current - Output (Typ) 50mA
Current - Quiescent (Max) 130μA
CMRR, PSRR (Typ) 66dB CMRR, 70dB PSRR
Propagation Delay (Max) 80ns
Hysteresis 5mV
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-5
Win Source Part Number 092932-MCP6561T-E/LT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MCP6561T-E/LT CAD Model

Description

Microchip Technology's MCP6561T-E/LT Comparator

The MCP6561T-E/LT is a high-performance, low-power comparator manufactured by Microchip Technology, renowned for its precision electronic components. This comparator is designed to provide a reliable solution for applications requiring voltage level detection and signal conditioning with minimal power consumption.

Key Features

  • Supply Voltage Range: The device operates from a single 2.5V to 5.5V power supply, making it suitable for both 3.3V and 5V systems.
  • Low Quiescent Current: With a typical quiescent current of just 1 µA, the MCP6561T-E/LT is ideal for battery-powered and portable applications where power efficiency is critical.
  • Propagation Delay: The device features a fast propagation delay of typically 4 µs, providing quick response times for high-speed signal processing.
  • Push-Pull Output: Its push-pull output stage eliminates the need for an external pull-up resistor and allows for direct interfacing with TTL and CMOS logic.
  • Input Offset Voltage: The MCP6561T-E/LT boasts a low input offset voltage, which enhances its accuracy in precision applications.
  • Temperature Range: It is designed to operate over the extended industrial temperature range of -40°C to +125°C, ensuring reliability in harsh environments.
  • Package Options: The comparator is available in a small 5-pin SC-70 package, which is ideal for space-constrained applications.

Applications

The versatility of the MCP6561T-E/LT allows it to be used in a wide array of applications, including:

  • Battery monitoring
  • Window detectors
  • Signal wave-shaping
  • IR receivers
  • Threshold detection
  • Portable instrumentation

The MCP6561T-E/LT from Microchip Technology is a testament to the company's commitment to providing high-quality, precision-engineered solutions to meet the needs of modern electronic systems. Whether you are designing a simple voltage level detector or a complex signal processing circuit, the MCP6561T-E/LT offers a reliable and power-efficient option.
