Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT, N-Channel MOSFET
Supply Voltage (V) 4.5V ~ 18V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 12A, 12A
Input Type Inverting
Rise / Fall Time 20ns, 24ns
Temperature Range - Operating 0°C ~ 70°C
Mounting Style Through Hole
Manufacturer Package TO-220-5
Supplier Device Package TO-220-5
Family Part Number MIC4451
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1222567-MIC4451ZT
Manufacturer Homepage www.micrel.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MIC4451ZT CAD Model

Description

Microchip Technology's MIC4451ZT MOSFET Driver

The MIC4451ZT from Microchip Technology is a robust and highly efficient MOSFET driver designed to cater to a wide range of applications requiring high-speed operation and the capability to drive large capacitive loads with ease. This particular component is part of Microchip's MIC4451 series and comes in a convenient through-hole package, making it suitable for various types of circuit boards and design topologies.

Key Features

  • High Peak Output Current: The MIC4451ZT can deliver a peak output current of up to 12A, making it an ideal choice for driving large power MOSFETs and IGBTs that require high current for rapid switching.
  • Wide Operating Voltage Range: With an operational range of 4.5V to 18V, this driver can accommodate a variety of control logic levels and is compatible with standard TTL and CMOS logic families.
  • Low Propagation Delays: The device boasts fast propagation delays and rise/fall times, ensuring minimal delay between input signal and output response, which is crucial for high-frequency applications.
  • Latch-Up Protection: The MIC4451ZT includes built-in latch-up protection, enhancing the reliability and robustness of the device under extreme conditions.
  • Under-Voltage Lockout (UVLO): This safety feature ensures that the driver operates only when the supply voltage is within an acceptable range, protecting the MOSFETs from insufficient gate voltage.

Applications

The versatility of the MIC4451ZT makes it suitable for a variety of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Motor control circuits
  • Class D switching amplifiers
  • Pulse transformer drivers

With its impressive current handling capability and fast switching performance, the MIC4451ZT is a reliable choice for design engineers looking to improve efficiency and performance in their high-power electronic systems. Microchip Technology's commitment to quality ensures that this MOSFET driver will deliver consistent performance and contribute to the longevity and reliability of the end application.
