Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Switch Type Latched Driver
Number of Outputs 8
Output Type Bipolar
Voltage - Load 15V (Max)
Current - Output (Max) 500mA
Input Type Non-Inverting
Temperature Range - Operating -55°C to 85°C (TA)
Case / Package 18-SOIC W
Win Source Part Number 130401-MIC5841BWM
Ultra Librarian 3D Model Ultra Librarian MIC5841BWM CAD Model

Description

Microchip Technology MIC5841BWM Overview

The MIC5841BWM is a robust integrated circuit designed and manufactured by Microchip Technology, a leading provider in the semiconductor industry. This device is part of the family of 8-bit serial-input latched drivers, which are specifically engineered to control LEDs, relays, and other high-voltage, high-current loads with a minimal number of components and connections.

Key Features

  • Output Voltage: The MIC5841BWM is capable of providing an output voltage of 50V, making it suitable for a variety of high-voltage applications.
  • Output Current: Each of the eight output drivers can sink up to 500mA, allowing it to drive a wide range of loads.
  • Integrated Clamp Diodes: Built-in clamp diodes are included for inductive transient suppression, which is particularly important when driving inductive loads such as relays and motors.
  • Serial Interface: The device accepts data via a serial input (SI), which can be cascaded with additional devices for extended output capability without requiring additional microcontroller I/O lines.
  • Latch Enable (LE) Function: The MIC5841BWM features a latch enable function that allows the user to update the output latches at their convenience.
  • Output Enable (OE) Function: An output enable function provides the user with the ability to disable all outputs simultaneously, which is useful for power-saving modes and safety.

Applications

The MIC5841BWM is versatile and can be used in a wide array of applications, including:

  • LED displays and signage
  • Relay driving circuits
  • Industrial controls
  • Peripheral drivers

Package and Quality

The device is offered in a 22-pin Wide Body SOIC package, which is suitable for surface-mount technology (SMT) and is compatible with standard PCB manufacturing processes. Microchip Technology is known for its commitment to quality, and the MIC5841BWM is no exception, meeting high standards for reliability and performance.

With its robust design, ease of use, and Microchip's reputation for quality, the MIC5841BWM is an excellent choice for designers looking to control high-current loads with precision and efficiency.
