Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 0.5V
Maximum Output Voltage 5.5V
Dropout Voltage-Max 0.5V @ 5A
Output Current 5A
Operating Supply Current 5mA to 150mA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package S-PAK-7
Win Source Part Number 1077201-MIC69502WR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MIC69502WR CAD Model

Description

The MIC69502WR from Microchip Technology is a high-performance, adjustable output, low-dropout voltage regulator (LDO) capable of delivering up to 5A of continuous current. This robust voltage regulator is designed to provide a stable and reliable power supply for a wide range of applications, including sensitive RF and digital integrated circuits that require a precise and clean voltage source.

Key Features

  • High Output Current: Capable of delivering up to 5A of continuous output current, making it suitable for high-power applications.
  • Adjustable Output Voltage: The output voltage is adjustable from 1.25V to 5V, which allows for flexibility in various design requirements.
  • Low Dropout: The low dropout voltage ensures efficient operation even when the input voltage is close to the output voltage, thereby reducing power loss and improving efficiency.
  • Excellent Load Regulation: The MIC69502WR maintains a stable output voltage despite changes in the load, ensuring a reliable power supply for sensitive components.
  • Thermal and Overcurrent Protection: Built-in thermal and overcurrent protection safeguards the device and the system from damage due to excessive heat or current.
  • Stable with Ceramic Capacitors: Stable operation with low-ESR ceramic output capacitors, which reduces the size and cost of the power supply design.

Applications

The MIC69502WR is ideal for a variety of applications, including:

  • High-performance DSP and FPGA power supplies
  • Networking and telecommunication equipment
  • Server and storage systems
  • Industrial and medical equipment

Product Specifications

Parameter Value Output Current 5A Adjustable Output Voltage 1.25V to 5V Dropout Voltage Low Package TO-263 (D2PAK)

The MIC69502WR from Microchip Technology is a versatile and reliable solution for high-current applications that require a high-quality power supply. Its combination of performance, flexibility, and protection features makes it an excellent choice for designers looking to optimize their power systems.
