Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features series Microcontroller IC
Manufacturer Microchip Technology
Series PIC® XLP™ 16F
Package Tube
Number of I/O 12
Family Name PIC16F1823
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Quantity per package 96
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 851818-PIC16F1823-E/ST
Ultra Librarian 3D Model Ultra Librarian PIC16F1823-E/ST CAD Model

Description

Microchip Technology's PIC16F1823-E/ST Microcontroller

The PIC16F1823-E/ST is a high-performance microcontroller unit (MCU) from the renowned semiconductor manufacturer, Microchip Technology. This compact yet powerful MCU is part of Microchip's extensive PIC16F family, known for its versatility and reliability in a wide range of embedded applications. The PIC16F1823-E/ST is particularly well-suited for automation, consumer electronics, automotive, and industrial control systems.

At the heart of the PIC16F1823-E/ST lies an enhanced Mid-range 8-bit core with an integrated EEPROM, which offers a perfect balance between power consumption and processing capability. With its operating voltage ranging from 1.8V to 5.5V, it provides designers with the flexibility to support battery-powered and low-power applications.

The MCU is equipped with a 7 KB of flash memory and 256 bytes of RAM, which allows for efficient handling of code and data. The device also features 128 bytes of EEPROM, which is essential for non-volatile storage of configuration or calibration data that must be preserved through power cycles.

One of the standout features of the PIC16F1823-E/ST is its extensive set of peripherals. It includes an Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART), which enables serial communication with other MCUs or peripheral devices. Additionally, it boasts two comparators, a 10-bit Analog-to-Digital Converter (ADC) with up to 12 channels, and a Capture/Compare/PWM (CCP) module for advanced timing and control operations.

For ease of programming and debugging, the MCU supports In-Circuit Serial Programming™ (ICSP™) and In-Circuit Debug (ICD) via two pins. Furthermore, the device comes in a space-saving TSSOP-14 package, making it ideal for applications where board space is at a premium.

The PIC16F1823-E/ST is also supported by Microchip's MPLAB® IDE and MPLAB® XC8 compiler, providing developers with a comprehensive development environment to bring their applications to market quickly and efficiently. With its robust feature set and broad operating voltage range, the PIC16F1823-E/ST is a versatile choice for designers looking to leverage Microchip's legacy of quality and innovation in their next project.
