Products specifications

Category Integrated Circuits (ICs)>PMIC - Gate Drivers
Mfr Microchip Technology
Series Military, MIL-STD-883
Package Tray
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel MOSFET
Voltage - Supply 22V
Logic Voltage - VIL, VIH 0.7V, 2V
Current - Peak Output (Source, Sink) 3A
Input Type Inverting
Rise / Fall Time (Typ) 30ns, 30ns
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Through Hole
Package / Case TO-99-8 Metal Can
Supplier Device Package TO-99
Base Product Number SG1626
Other Names 150-SG1626T
Standard Package 50
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1253504-SG1626T
Ultra Librarian 3D Model Ultra Librarian SG1626T CAD Model

Description

The SG1626T from Microchip Technology is a robust and versatile integrated circuit designed to cater to a wide array of applications in the modern electronics landscape. This high-performance component is an essential building block in power management, motor control, and various other industrial and consumer applications.

Key Features

  • High Current Capability: The SG1626T is engineered to handle high current applications, ensuring reliability and efficiency in power-intensive operations.
  • Flexible Voltage Range: This device operates over a broad voltage range, accommodating various power supply requirements and making it suitable for multi-voltage systems.
  • Durable Construction: Built with Microchip's commitment to quality, the SG1626T is designed for longevity and stable performance even in challenging environmental conditions.
  • Precision Control: Precision control features are integrated into the SG1626T, allowing for accurate power delivery and management, which is crucial for sensitive electronic components.

Applications

The SG1626T is adept at serving in multiple roles across different sectors, including:

  • Switching power supplies
  • Motor control systems
  • DC-DC converters
  • Battery chargers
  • Power inverters

Product Specifications

Attribute Value Package / Case TO-220-7 (Formed Leads) Mounting Type Through Hole Operating Temperature -55°C to +125°C RoHS Status Compliant

With its combination of reliability, versatility, and Microchip's renowned engineering expertise, the SG1626T is an excellent choice for your advanced electronic designs. Whether you're developing the next generation of power supplies or innovating in motor control, the SG1626T offers the performance and quality that professionals trust.
