Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Type Transceiver
Number of Drivers/Receivers 1/1
Data Rate 4.25Gbps
Supply Voltage (V) 3V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 24-VFQFN Exposed Pad, 24-MLF
Supplier Device Package 24-MLF (4x4)
Family Part Number SY58620
Manufacturer Pack Quantity 75
MSL Level 2 (1 Year)
Win Source Part Number 1263065-SY58620LMG
Manufacturer Homepage www.micrel.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SY58620LMG CAD Model

Description

Microchip Technology's SY58620LMG: A High-Performance CML Buffer/Translator

The SY58620LMG from Microchip Technology is a robust, high-speed Current Mode Logic (CML) buffer/translator designed to deliver exceptional performance in demanding applications. This versatile device is an excellent choice for engineers looking for a reliable solution to manage high-speed data transmission with minimal signal degradation.

With a design optimized for low skew and high-speed operation, the SY58620LMG is capable of handling data rates up to 12.5 Gbps, making it ideal for applications in networking, telecommunications, and high-performance computing. Its differential input includes an internal termination resistor, allowing for direct connection to CML, LVDS, LVPECL, or standard ECL outputs without additional external components.

The device features a 2:1 MUX input, which provides added flexibility for signal routing and multiplexing. The SY58620LMG operates from a 2.5V ±5% core power supply, and its outputs can be terminated to a positive supply voltage in order to interface with PECL or CML logic levels. This adaptability ensures easy integration into a wide range of system architectures.

Key attributes of the SY58620LMG include its fast propagation delay and rise/fall times, which contribute to its high-speed capabilities. Additionally, the device offers a fail-safe input structure that guarantees a known output state when input signals are idle, floating, or terminated improperly. This feature is critical for maintaining system integrity and reliability.

For ease of implementation, the SY58620LMG is available in a space-saving 3x3 mm 16-pin QFN package, which is both compact and offers excellent thermal performance. Its small footprint allows for high-density board layouts, which is particularly beneficial in systems where board space is at a premium.

In summary, the SY58620LMG from Microchip Technology stands out as a high-performance solution for engineers seeking a CML buffer/translator that offers speed, flexibility, and reliability. Whether employed in data communications, computing, or other high-speed signal processing applications, this device is engineered to meet the stringent requirements of today's advanced electronic systems.
