The Molex 39522-1003 is a Micro-Fit 3.0 BMI Panel Mount Receptacle Housing. This receptacle housing is designed for wire-to-wire and wire-to-board applications, offering a compact solution where space is limited. It ensures secure connections and reliable performance in various electronic systems.

Applications

• Consumer electronics
• Automotive applications
• Industrial controls
• Data networking
• Telecommunications equipment

Features

• Micro-Fit 3.0 connector family
• Panel mountable
• Single row configuration
• Durable housing material
• Positive locking mechanism to prevent accidental disconnections
• Polarization features to ensure correct mating
• Compact design for high-density applications
• Black color

Benefits

• Provides a reliable and secure connection
• Saves space in compact electronic devices
• Easy to install with panel mount design
• Prevents mismating and ensures proper connection
• Durable construction ensures long-term performance
• Reduces downtime and maintenance costs
• Supports high-density packaging requirements

Additional Details

The 39522-1003 receptacle housing is made from a high-quality, durable material ensuring reliability in demanding environments. It features a positive locking mechanism that provides a secure connection, preventing accidental disconnections due to vibration or other external factors. The panel mount design allows for easy installation and maintenance. This connector is designed to work with Micro-Fit 3.0 series terminals and headers, offering a complete interconnect solution. It has a 3.0mm pitch and is suitable for applications requiring a compact, high-performance connector.
