Same model may have multiple batches, images only for reference.

82154C

Name: 82154C
Brand: Murata Power Solutions Inc.
SKU: 1328066
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	82154C
Manufacturer	Murata Power Solutions Inc.
Catalog	Fixed Inductors
Description	FIXED IND 150UH 130MA 5.9OHM SMD / 150 µH Unshielded Wirewound Inductor 130 mA 5.9Ohm Max 1210 (3225 Metric)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Manufacturer	Murata Power Solutions Inc.
Packaging	Reel - TR
Type	Wirewound
Inductance	150 µH
Tolerance	±10%
Current Rating (Amps)	130 mA
Shielding	Unshielded
DC Resistance (DCR)	5.9Ohm Max
Q @ Freq	40 @ 800kHz
Frequency - Self Resonant	11MHz
Temperature Range - Operating	-40°C ~ 85°C
Inductance Frequency - Test	10 kHz
Mounting	Surface Mount
Case / Package	1210 (3225 Metric)
Supplier Device Package	1210
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	0.091" (2.30mm)
Base Product Number	82
RoHS Status	ROHS3 Compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Other Part Number	811-2480-2,811-2480-1,811-2480-6
Standard Package	2,500
Win Source Part Number	1328066-82154C
Ultra Librarian 3D Model	Ultra Librarian 82154C CAD Model

Alternative Products

Description

The 1141621 is a wirewound fixed inductor manufactured by Murata Power Solutions Inc.

Inductance: 150 μH
Tolerance: ±10%
Shielding: Unshielded
Standard Package: 2,500
Mounting Type: Surface Mountable
DC Resistance (DCR): 5.9Ohm Max
Q @ Freq: 40 @ 800kHz
Frequency - Self-Resonant: 11MHz
Temperature Range: -40°C ~ 85°C
Supplier Device Package: 1210
Current Rating: 130 mA
Inductance Frequency-Test: 10 kHz
ROHS3 Compliant: Yes
REACH: Unaffected
Applications: Power Supply, Filter, and DC/DC Converter
