Products specifications

Category Discrete Semiconductor Products
Family Variable Capacitance Diodes(Varicaps,Varactors)
Manufacturer NXP
Win Source Part Number 231872-BB148
Popularity Medium
Supply and Demand Status Limited
Family Name BB148
Introduction Date December 01, 1994
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian BB148 CAD Model

Description

The NXP BB148 is a high-performance varactor diode designed for use in a wide range of applications, from voltage-controlled oscillators (VCOs) to RF and microwave circuits. This versatile component is known for its excellent tuning ratio and low series resistance, making it an ideal choice for designers who require reliable and precise frequency tuning capabilities.

Key Features

  • High Tuning Ratio: The BB148 offers a significant tuning ratio, allowing for substantial frequency changes with small variations in tuning voltage. This feature is particularly beneficial for VCOs in phase-locked loops (PLLs), where precise frequency control is paramount.
  • Low Series Resistance: With its low series resistance, the BB148 ensures minimal insertion loss and improved signal quality. This characteristic is crucial for maintaining the integrity of high-frequency signals.
  • Wide Voltage Range: The diode operates over a broad range of reverse bias voltages, giving designers the flexibility to use it in various circuit configurations and applications.
  • Compact Package: The BB148 comes in a small SOD323 (SC-76) surface-mount package, which is suitable for space-constrained applications and allows for high-density PCB layouts.

Applications

The BB148 is commonly employed in:

  • RF tuners and receivers
  • Microwave frequency synthesizers
  • Electronic tuning systems
  • Mobile communications devices
  • Satellite communication systems

Technical Specifications

Parameter Value Package SOD323 Tuning Ratio High Series Resistance Low Operating Voltage Range Wide

With its robust performance and flexible usage, the NXP BB148 varactor diode is a top-tier component for engineers looking to develop cutting-edge RF and microwave systems. Its reliability and high-quality construction make it a staple in the industry for frequency tuning applications.
