Products specifications

Manufacturer NXP
Win Source Part Number 1151831-BBY40
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name BBY40
Introduction Date August 19, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian BBY40 CAD Model

Description

The NXP BBY40 is a high-performance variable capacitance diode, also known as a varicap or varactor diode, designed for use in a wide array of electronic applications. This diode is specifically engineered to provide excellent tuning and filtering functionalities within VHF and UHF television tuners, FM tuners, and other RF circuits. The BBY40 is a versatile component that offers designers the ability to achieve precise electronic tuning, making it an essential part of modern electronics where variable capacitance is required.

Key Features

  • Variable Capacitance: The BBY40's capacitance varies with the voltage applied to it, which allows for electronic tuning of RF circuits without the need for mechanical tuning components.
  • High-Quality Factor: With a high Q factor, the BBY40 provides low series resistance and high resonance quality, making it suitable for high-frequency applications.
  • Low Series Resistance: The low series resistance of the BBY40 ensures minimal signal loss, contributing to the efficiency and performance of the overall circuit.
  • Consistent Performance: The BBY40 is known for its consistent performance over a wide temperature range, ensuring reliability in various operating conditions.

Applications

The NXP BBY40 is used in a variety of applications, including:

  • Electronic tuning in VHF and UHF television tuners
  • FM tuners and RF oscillators
  • Phase-locked loops (PLLs) for frequency synthesis
  • Voltage-controlled oscillators (VCOs)
  • Bandpass and band-stop filters

Technical Specifications

The BBY40 offers the following technical specifications:

  • Package: SOD-323
  • Reverse Voltage: 30 V
  • Diode Capacitance Range: 1.8 pF to 20 pF
  • Quality Factor: > 500 at 50 MHz

In conclusion, the NXP BBY40 is a reliable and efficient varicap diode that provides design flexibility and performance for RF tuning applications. Its high-quality factor, low series resistance, and consistent performance make it a preferred choice for electronics designers and engineers looking to create sophisticated, high-frequency electronic products.
