NXP ISP1761BEUM Product Overview

The NXP ISP1761BEUM is a versatile and high-performance Hi-Speed USB On-The-Go (OTG) controller, designed to cater to the increasing demand for advanced USB connectivity solutions in a wide range of applications. This state-of-the-art device is an ideal choice for manufacturers looking to incorporate USB functionality into their products, with its ability to act as either a host or a peripheral, depending on the requirements of the application.

Key Features

• High-Speed USB 2.0 Interface: The ISP1761BEUM supports data transfer rates of up to 480 Mbps, making it suitable for applications requiring fast data exchange.
• On-The-Go Capabilities: With OTG support, the device can function as a limited host or a peripheral, providing flexibility in USB connectivity and enabling direct communication between devices without the need for a PC.
• Multiple Interface Options: It includes a parallel interface for connection to microcontrollers or processors, and a serial interface for communication with other serial-enabled devices.
• Integrated PHY: The built-in Physical Layer (PHY) transceiver reduces the need for external components, thus saving space and cost in the design.
• Flexible Memory Architecture: The ISP1761BEUM offers a programmable memory architecture that can be tailored to match specific system requirements.

Applications

The NXP ISP1761BEUM is well-suited for a variety of applications, including but not limited to:

• Portable media players
• Printers and multifunction peripherals
• Mobile phones and smartphones
• Digital cameras and camcorders
• Networking and communication devices
• Automotive infotainment systems

Technical Specifications

The device comes in a compact QFN-64 package and operates over a temperature range of -40°C to 85°C, ensuring reliability and performance under varying environmental conditions. With its integrated power management features, the ISP1761BEUM also enables energy-efficient operation, which is critical for battery-powered devices.

In summary, the NXP ISP1761BEUM is a feature-rich USB OTG controller that offers designers the flexibility, performance, and ease of integration required for the next generation of USB-enabled devices.
