Products specifications Report Issue?

Categories Sensors
Estimated Pruduction Lead Time 25 Weeks
Features Pressure Sensor 1.45PSI (10kPa) Vented Gauge Male - 0.19" (4.93mm) Tube 0 mV ~ 25 mV (10V) 4-SIP Module
Manufacturer NXP
Series MPX2010
Package Tray
Operating Temperature Range -40°C ~ 125°C
Package 4-SIP Module
Family Name MPX2010
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Quantity per package 100
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 885873-MPX2010GP
Ultra Librarian 3D Model Ultra Librarian MPX2010GP CAD Model

Description

Introducing the MPX2010GP Pressure Sensor from NXP

The MPX2010GP is a highly reliable and accurate piezoresistive pressure sensor from NXP Semiconductors, designed to provide a cost-effective solution for a wide range of applications. This sensor is a staple in the industry, known for its robust performance and versatility in measuring differential pressure.

Key Features

  • Sensitivity: The MPX2010GP offers a high sensitivity of 2.0 mV/V/kPa, making it capable of detecting even the slightest changes in pressure.
  • Pressure Range: It operates within a pressure range of 0 to 10 kPa, suitable for various applications including medical systems, industrial controls, and consumer products.
  • Accuracy: With an impressive accuracy level, this sensor ensures precise pressure measurements, which is critical for maintaining the integrity of any pressure-dependent system.
  • Durability: Encased in a rugged, unibody package, the MPX2010GP is built to withstand harsh environments and maintain its performance over a long lifespan.
  • Temperature Compensated: The sensor includes temperature compensation ranging from 0°C to +85°C, ensuring reliable operation across various temperature conditions.

Applications

The versatility of the MPX2010GP makes it suitable for a broad spectrum of applications, including:

  • Medical devices such as respiratory equipment and blood pressure monitors
  • Level and flow measurements in industrial systems
  • Environmental controls for air conditioning and ventilation systems
  • Consumer applications like washing machine water level sensing

Easy Integration

Designed for ease of integration, the MPX2010GP comes in a standard 4-pin case 344C-01 package. It provides a simple, analog output that can be easily interfaced with a variety of microcontrollers and analog-to-digital converters. The sensor's small size and low weight make it an excellent choice for designs where space and weight are at a premium.

Conclusion

Whether you're developing sophisticated medical equipment or need reliable pressure sensing for industrial machinery, the MPX2010GP from NXP stands out as a top choice for designers and engineers. Its combination of sensitivity, accuracy, and durability, packaged in a user-friendly form factor, ensures it will continue to be a valued component in pressure sensing solutions.
