Products specifications

Manufacturer NXP
Win Source Part Number 1236020-PCA9546ABS
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9546ABS CAD Model

Description

Product Overview: PCA9546ABS by NXP

The PCA9546ABS is a versatile and high-performance 4-channel I2C-bus switch with an interrupt logic, designed and manufactured by NXP Semiconductors. This innovative component is engineered to provide seamless communication and control for complex I2C systems, ensuring efficient and reliable operation in a wide range of applications.

Key Features

  • Channel Number: The PCA9546ABS boasts four bidirectional translating switches that can connect multiple I2C devices with different voltage levels to a single I2C bus, thus simplifying design and saving space.
  • Low Standby Current: It is optimized for low power consumption, featuring a standby current of just 2 µA (typical), which is ideal for battery-powered and energy-saving applications.
  • Interrupt Logic: Each switch has an interrupt input associated with it, allowing the master to acknowledge when a connected device requires attention, enhancing system responsiveness and efficiency.
  • High Noise Immunity: With built-in glitch-free operation, the PCA9546ABS is designed to withstand the rigors of noisy environments, ensuring reliable communication between devices.

Applications

The PCA9546ABS is suitable for a broad array of applications, including but not limited to server management, power management systems, and multiple zone environments where several I2C devices need to be controlled independently. Its ability to interface with different logic levels makes it particularly useful in applications that require communication between devices operating at different voltages.

Technical Specifications

  • Supply Voltage Range: 2.3V to 5.5V, accommodating a variety of system power requirements.
  • Operating Temperature: The device is rated for operation between -40°C and +85°C, ensuring reliability across a wide range of environmental conditions.
  • Packaging: Offered in a TSSOP-16 package, the PCA9546ABS is compact and suitable for space-constrained applications.

Overall, the PCA9546ABS from NXP is a robust and flexible solution for expanding I2C bus capabilities, providing designers with a simple and effective way to manage multiple I2C devices within their electronic systems.
