Products specifications

Manufacturer NXP
Win Source Part Number 1239145-PMV48XP
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMV48XP CAD Model

Description

The NXP PMV48XP is a state-of-the-art, high-performance Metal-Oxide Semiconductor Field-Effect Transistor (MOSFET) designed to meet the demands of modern electronic circuits. This compact semiconductor device is engineered to deliver efficient power management and signal processing capabilities in a wide range of applications.

Key Features

  • Low On-Resistance: The PMV48XP boasts an exceptionally low on-resistance, which significantly reduces power losses and improves overall efficiency in electronic circuits.
  • High-Speed Switching: With its fast switching capabilities, this MOSFET is ideal for high-frequency applications, ensuring that power conversion is both smooth and efficient.
  • Enhanced Thermal Performance: The device is encapsulated in a leadless ultra-thin small flat package, which not only saves space but also offers superior thermal performance, making it suitable for high-temperature operations.
  • Low Threshold Voltage: The low threshold voltage of the PMV48XP ensures that it can be easily driven by low-voltage control signals, making it compatible with modern microcontrollers and digital logic levels.

Applications

The versatility of the NXP PMV48XP MOSFET allows it to be used across various sectors, including:

  • Power Management for portable devices
  • DC/DC Converters
  • Load Switching
  • Battery Management Systems
  • Motor Control Circuits

Technical Specifications

Parameter Value Drain-Source Voltage (V<sub>DS) 20V Continuous Drain Current (I<sub>D) 4.3A Power Dissipation (P<sub>D) 1.25W On-State Resistance (R<sub>DS(on)) 54 mΩ

Overall, the NXP PMV48XP is an exceptional choice for designers looking to enhance the efficiency and reliability of their power-sensitive applications. With its advanced features and robust performance, it stands out as a leading solution in the field of power MOSFETs.
