Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube/Rail
Status Obsolete(EOL)
Mounting Through Hole
Case / Package 9-SIL
Win Source Part Number 053487-TDA8351
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TDA8351 CAD Model

Description

The NXP TDA8351 is a high-performance integrated circuit designed specifically for use in television sets and monitors. This IC is part of NXP's extensive range of solutions for audio and visual applications, offering reliability and innovation in a compact package.

Key Features:

  • Vertical Deflection Booster: The TDA8351 includes a vertical deflection booster that enables it to drive the vertical deflection coil in a TV set. This feature allows for a stable and consistent vertical scan, ensuring a clear and flicker-free image.
  • Power Amplifier: With an integrated power amplifier, the TDA8351 can directly drive the deflection yoke, including the required deflection current, without the need for additional external components.
  • Thermal Protection: The device is equipped with thermal protection circuitry that prevents overheating, ensuring long-term reliability and safety in operation.
  • East-West Correction: The IC also provides east-west pin cushion correction capability, which is essential for maintaining the correct aspect ratio and geometry of the displayed image.

Applications:

The TDA8351 is suitable for a wide range of applications in the field of consumer electronics, particularly where vertical deflection systems are required:

  • Television sets (CRT TVs)
  • Computer monitors
  • Display units requiring vertical deflection

Technical Specifications:

The TDA8351 operates over a wide supply voltage range and is compatible with various microcontroller interfaces. Its compact design makes it an ideal choice for space-constrained applications. The IC's high integration level reduces the overall component count, which enhances system reliability and simplifies the design process.

Quality and Support:

NXP is known for its commitment to quality, and the TDA8351 is no exception. It is manufactured to meet high standards, ensuring consistent performance and durability. Additionally, NXP provides comprehensive technical support for its products, including detailed datasheets, application notes, and design-in support to help engineers integrate the TDA8351 into their designs successfully.
