2N6027RLRAG

Part No 2N6027RLRAG
Manufacturer ON Semiconductor
Catalog Programmable Unijunction Transistors (PUTs)
Description THYRISTOR PROG UNIJUNCT 40V TO92
Datasheet
Sample
ECAD Module ECAD
rohs

Shipping Information

Shipped from HK warehouse
Expected Shipping Date
Ship today if order in (HKT)
Supplier Lead-Time Call for availability
Estimate shipping fee
Enter your destination to get a shipping estimate
Estimate Shipping Fee
Pricing & Ordering $1.2658 Historical reference price : is the price that a customer announces that it is willing to pay for this component in the previous period, only for reference.
Quantity
Unit Price
Ext. Price
30+
$1.6960
$50.880
75+
$1.3920
$104.400
115+
$1.3480
$155.020
155+
$1.3050
$202.275
200+
$1.2610
$252.200
270+
$1.1310
$305.370
* The above prices does not include taxes and freight rates, which will be calculated on the order pages.
Availability: 91,900 pieces
MOQ: 30 pcs
Order Increment : 1 pcs
*Need More Quantity? *Request a Bulk Quantity Quotation?
Estimate shipping
Enter your destination to get a shipping estimate

*

Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Status Obsolete(EOL)
Voltage 40V
Power Dissipation (Max) 300mW
Output Voltage 11V
Voltage - Offset (Vt) 1.6V
Current - Gate to Anode Leakage (Igao) 10nA
Current - Valley (Iv) 50μA
Current - Peak 2μA
Dimension TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Win Source Part Number 096428-2N6027RLRAG
Is this a common-used part? Yes
Popularity High
Fake Threat In the Open Market 34 pct.
Supply and Demand Status Sufficient

Description

ON Semiconductor 2N6027RLRAG Programmable Unijunction Transistor

The ON Semiconductor 2N6027RLRAG represents a versatile and reliable programmable unijunction transistor (PUT) designed for a wide array of applications requiring a dependable thyristor device. This PUT is specifically engineered to exhibit characteristics similar to the conventional unijunction transistor but with an added ability to modify its intrinsic standoff ratio, providing enhanced flexibility in various electronic circuit designs.

With its adjustable anode-to-gate voltage, the 2N6027RLRAG allows designers to tailor the triggering point of the device according to specific circuit requirements. This feature makes it an ideal component for precision timing circuits, oscillators, and pulse generation applications where control over the firing angle is crucial.

The device is encapsulated in a TO-92 package, which is a compact and widely used form factor for through-hole mounting, ensuring compatibility with a broad range of printed circuit boards and easy integration into existing designs. The 2N6027RLRAG is characterized by its high peak output voltage of 40V and a peak output current of 300mA, making it suitable for driving small loads directly or as a triggering element for larger thyristors.

Some key features of the 2N6027RLRAG include:

  • Programmable unijunction characteristics
  • Peak output voltage (VBO): 40V
  • Peak output current (IEM): 300mA
  • Gate to anode voltage (VGT): 0.2V to 0.8V
  • TO-92 package for easy integration
  • Through-hole mounting for robust mechanical stability
  • High reliability and performance consistency

Applications for the 2N6027RLRAG are diverse, ranging from simple delay circuits to more complex analog and digital electronics. It is commonly used in waveform generators, thyristor trigger circuits, and as a switch in industrial control systems. ON Semiconductor's commitment to quality ensures that each 2N6027RLRAG PUT meets stringent standards, providing designers with a dependable component for their electronic projects.

Whether you are working on a hobbyist project or developing commercial electronics, the ON Semiconductor 2N6027RLRAG is a solid choice for a programmable unijunction transistor that offers both performance and adaptability.
