Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tube
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 300V
Current - Average Rectified (Io) (per Diode) 16A
Voltage - Forward (Vf) (Maximum) at If 1.3V at 8A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 50ns
Current - Reverse Leakage at Vr 10μA at 300V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package TO-220-3
Supplier Device Package TO-220-3
Family Part Number FEP16F
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1173970-FEP16FT
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian FEP16FT CAD Model

Description

ON Semiconductor FEP16FT Fast Recovery Rectifier

The ON Semiconductor FEP16FT is a high-performance fast recovery rectifier designed to meet the demanding requirements of modern electronic circuits. This device features a fast switching speed and low forward voltage drop, making it ideal for high-efficiency power supply designs and various other applications where fast switching is crucial.

Key Features:

  • High Speed: With a recovery time as low as 50 nanoseconds, the FEP16FT is optimized for fast switching applications, reducing losses and improving overall efficiency.
  • High Voltage Capability: The rectifier can withstand repetitive peak reverse voltages up to 600V, providing a comfortable safety margin for transient voltage spikes.
  • High Current Rating: It has a forward current rating of 16A, allowing it to handle significant power levels in a compact form factor.
  • Low Forward Voltage Drop: The low forward voltage drop reduces power dissipation and improves thermal performance, which is critical in high-power and high-frequency applications.
  • Robust Construction: Encased in a TO-220 full-pack package, the FEP16FT offers enhanced thermal performance and mechanical durability.

Applications:

The FEP16FT is suitable for a variety of applications, including:

  • Switching power supplies
  • Power inverters
  • Motor controllers
  • Freewheeling diodes
  • Snubber circuits
  • Other high-speed rectification circuits

Technical Specifications:

Parameter Value Package TO-220 FullPak Repetitive Peak Reverse Voltage (V<sub>RRM) 600V Average Forward Current (I<sub>F(AV)) 16A Forward Voltage Drop (V<sub>F) 1.3V @ 16A Recovery Time (t<sub>rr) 50ns

With its combination of speed, efficiency, and reliability, the ON Semiconductor FEP16FT fast recovery rectifier is a solid choice for engineers looking to enhance the performance of their power conversion systems.
