The ON Semiconductor MC14013BCPG is a high-quality integrated circuit that belongs to the family of dual type D flip-flops. This versatile component is designed to be used in a wide array of electronic applications where reliable bistable state storage is required. The flip-flop is a fundamental building block in digital circuits, commonly used for data storage, data transfer, and synchronization tasks.

Key Features

• Voltage Range: The MC14013BCPG operates within a voltage range of 3V to 18V, making it compatible with both TTL (Transistor-Transistor Logic) and CMOS (Complementary Metal-Oxide-Semiconductor) logic levels.
• Output Current: This device is capable of sourcing or sinking up to 6.8mA of output current, providing adequate drive capability for interfacing with other logic devices.
• Propagation Delay: The flip-flop features a typical propagation delay time of 80ns, ensuring swift response times for high-speed applications.
• Set-Reset Capability: Each flip-flop includes independent set and reset functions, allowing for greater flexibility and control within circuit designs.
• Temperature Range: It is designed to operate over an industrial temperature range from -55°C to +125°C, ensuring reliable performance under extreme conditions.
• Packaging: The device comes in a PDIP-14 (Plastic Dual In-line Package) format, which is easy to handle and suitable for through-hole mounting on printed circuit boards (PCBs).

Applications

The MC14013BCPG is ideal for use in a variety of applications, including but not limited to:

• Counters and dividers
• Shift registers
• Memory storage elements
• Control circuits
• Timing circuits

Quality and Reliability

ON Semiconductor is known for its commitment to quality and reliability, and the MC14013BCPG is no exception. It is manufactured to the highest standards, ensuring consistent performance and longevity. Whether for consumer electronics, automotive systems, or industrial controls, this flip-flop is an excellent choice for designers seeking a dependable logic solution.
