2N7002E Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Panasonic
Standard Package 1
Category Discrete Semiconductor Products
Family FETs - Single
Packaging Reel
FET Type MOSFET N-Channel Metal Oxide
FET Feature Standard
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25°C 300mA (Ta)
Rds On (Max) @ Id Vgs 3 Ohm @ 100mA 10V
Vgs(th) (Max) @ Id 3V @ 250µA
Gate Charge (Qg) @ Vgs 0.8nC @ 4.5V
Input Capacitance (Ciss) @ Vds 40pF @ 10V
Power - Max 350mW
Operating Temperature Range 150°C (TJ)
Mounting Style SMD/SMT
Package TO-236-3 SC-59 SOT-23-3
Manufacturer Device Package SOT-23-3 (TO-236)
Catalog N-Channel Standard FETs
Win Source Part Number 051921-2N7002E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name 2N7002E
Introduction Date October 10, 2013
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian 2N7002E CAD Model

Description

Product Description

The 2N7002E is an N-channel enhancement mode MOSFET that excels in all switching needs. Recognized for its dynamic signal switching and minimal drain-source resistance, this transistor offers adaptability in various electronic circuits.

Features and Benefits

  • Robust and reliable with enhanced thermal stability.
  • Fast switching speed reduces delay times in circuits.
  • Low gate threshold voltage for versatile design applications.
  • Small package design for space-constrained applications.

Applications

  • Battery-powered applications
  • Load switching applications
  • LED driver circuits
  • Portable electronic devices

This component is perfect for designers focused on efficiency and compact design, supporting the development of portable and space-efficient electronic solutions.
