Products specifications

RoHS State Request Verification
Manufacturer Panjit
Win Source Part Number 1246435-SB1640DC
Manufacturer Homepage www.panjit.com.tw
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SB1640DC CAD Model

Description

The SB1640DC is a Schottky Barrier Rectifier manufactured by Panjit. It is designed for high-efficiency rectification in power supplies, inverters, and other applications where low forward voltage drop and fast switching speeds are crucial.

Applications

  • Switching power supplies
  • Freewheeling diodes in inductive loads
  • Polarity protection
  • DC-DC converters
  • High-frequency inverters

Features

  • Low forward voltage drop
  • High surge current capability
  • High reliability
  • Fast switching speed
  • RoHS compliant

Benefits

  • Improved efficiency in power conversion circuits
  • Reduced power dissipation and heat generation
  • Enhanced system reliability due to robust design
  • Minimized switching losses at high frequencies
  • Environmentally friendly due to RoHS compliance

Additional Details

The SB1640DC has a typical forward voltage drop of around 0.5V and can handle a forward current of 16A. It has a reverse voltage rating of 40V. The device is typically packaged in a TO-220AB package for easy mounting and heat dissipation. The Schottky barrier construction provides a faster reverse recovery time compared to standard diodes, which minimizes switching losses. Refer to the datasheet for detailed specifications, including maximum ratings, thermal resistance, and reverse leakage current.
