Products specifications

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 78%
Frequency - Switching 66kHz, 132kHz
Power (Watts) 119W
Fault Protection Current Limiting, Over Temperature, Over Voltage
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package TO-220-7C
Mounting Through Hole
Win Source Part Number 089141-TOP256YN
Family Name TOP256
Introduction Date August 01, 2008
ECCN EAR99
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TOP256YN CAD Model

Description

The supply and demand status of this product is limited.

  • Type: integrated circuit
  • Topology: flyback
  • Duty Cycle: 78%
  • Maximum Power: 119W
  • Voltage Breakdown: 700V
  • Internal Switches: yes
  • Output Isolation: yes
  • Fault Protection: current limiting, over temperature, and over voltage
  • Case/Package: TO-220-7C
  • Operating Temperature: -40°C to 150°C
  • Alternative Parts: ICE3B5565I, ICE3B3065I, and ICE3A3565I
