Products specifications

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 78%
Frequency - Switching 66kHz
Power (Watts) 333W
Fault Protection Current Limiting, Over Temperature, Over Voltage
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package TO-220-7C
Mounting Through Hole
Win Source Part Number 090452-TOP261YN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TOP261
Introduction Date August 01, 2008
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian TOP261YN CAD Model

Description

The TOP261YN is a 333W power supply integrated circuit manufactured by Power Integrations.

  • Mounting: through-hole
  • Package: TO-220-7C
  • Topology: flyback
  • Duty Cycle: 78%
  • Switching Frequency: 66kHz
  • Breakdown Voltage: 700V
  • Output: isolated
  • Protection: current limiting, over-temperature, and over-voltage
  • Popularity: high
  • Status: active
  • Availability: until 2022
