RF2304TR RF Micro Devices RF2304TR real image
Same model may have multiple batches, images only for reference.
RF2304TR RF Micro Devices RF2304TR real image
RF2304TR RF Micro Devices RF2304TR real image
Same model may have multiple batches, images only for reference.

RF2304TR

Part No RF2304TR
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP GEN-PURP LOW-NOISE 8-SOIC
Datasheet
RF2304TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 300MHz to 2.5GHz
P1dB 7.5dBm (5.6mW)
Gain 8.5dB
Noise Figure 1.9dB
RF Type ISM, WLAN, FDD, TDD
Supply Voltage - Operating 2.7 V to 6 V
Operating Supply Current 7mA to 26mA
Test Frequency 900MHz
Case / Package 8-SOIC
Win Source Part Number 062483-RF2304TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RF2304TR CAD Model

Description

The RF Micro Devices 062483-RF2304TR is a medium popularity component with a balanced supply and demand status.

  • Status: Obsolete (EOL)
  • Category: RF/IF and RFID
  • Gain: 8.5dB
  • Noise Figure: 1.9dB
  • P1dB: 7.5dBm (5.6mW)
  • Frequency Range: 300MHz to 2.5GHz
  • Test Frequency: 900MHz
  • Suitable for: ISM, WLAN, FDD, and TDD RF types
  • Manufacturer: RF Micro Devices
  • Win Source Part Number: 062483-RF2304TR
