Same model may have multiple batches, images only for reference.
RF2362 Real Image
Same model may have multiple batches, images only for reference.

RF2362

Part No RF2362
Manufacturer RF Micro Devices
Catalog Coaxial Cables (RF)
Description SMA BULKHEAD JACK-AMC PLUG 150MM
Datasheet
RF2362 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Cable Assemblies
Manufacturer Amphenol RF Division
Status Active
Gender Female to Female
Style SMA to UMC
1st Connector SMA Female Jack
2nd Connector Ultra Miniature Coaxial Plug Female Socket, Right Angle
Length 5.906" (150.00mm)
Cable Type 1.13mm OD Coaxial Cable
Impedance 50 Ohm
Maximum Input Frequency 6GHz
Win Source Part Number 293338-RF2362
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RF2362 CAD Model

Description

The Amphenol RF Division 293338-RF2362 is a cable assembly with a length of 5.906" (150.00mm) and an impedance of 50 Ohm.

  • Cable Type: 1.13mm OD coaxial cable
  • Style: SMA to UMC
  • First Connector: SMA female jack
  • Second Connector: ultra miniature coaxial plug female socket with a right angle
  • Supply and Demand Status: balance
